Hii Friends in today's article or post our team is providing Very Important MCQ's Related DC Generator So if this remains helpful to you. You all can share this post with your friends.
- The back EMF in DC motor ……
Opposes the applied voltage
Aids the applied voltage
Aids the armature current
Provide the fine speed
- A DC motor takes a large current at starting
because ……..
The armature resistance is high
Back emf is low
Shunt field is producing weak field
Dirt on commutator
- Commutating poles are also known as ….
Main pole
Primary pole
Interpol
Pole Pitch
- A series motor will over speed when ……..
The load is increases
The field is open
The armature circuit is open
The load is removed
- The shaft torque in a DC motor is less than
total armature torque because of …… in the
motor
Cu loss Field loss
Iron and friction loss
Bearing loss only
- The resistance of shunt field winding as
compared to series field winding is ….
Less
More
Same
Double
- A 20 HP DC motor has 89.03% efficiency
at rated power. What are its total losses
1787 W
1232 W
2184 W
1572 W
- The current drawn by a 220 V dc motor of
armature resistance 0.5 ohm and back emf
200 V is …..
44 A
40 A
400 A
440 A
- The friction and windage loss in a DC
motor depends upon …..
Speed
Flux
Armature current
Field and armature resistance
- DC series motors are used in those
applications where ………. Is required
High starting torque
Constant speed
Low no load speed
Low starting torque
- ……. The motor is most suitable for punch
press
Shunt
Series
Differential compound
Cumulative compound
- Which motor is not be used for centrifugal
pumps
Shunt
Series
Cumulative compound
Differential compound
- The most commonly used method of
speed control of DC motor is by varying
…..
The voltage applied to the motor
Field strength
The effective number of a conductor in series
Armature circuit resistance
